KIND OF CONVOLUTION AND MOULDING PROCESS
|
Flexible hoses with helicoidal
convolution from DN 6 to DN 8 and in the superior diameter to DN
300, with parallel convolutions and strict thread and hydraulic
process, to assure an high flexibility.
|
STANDARD SUPPLY MATERIALS
|
Stainless steel AISI 321 and AISI
316L.
|
STANDARD PLAITS
|
One or two
braids with stainless steel AISI 304
|
KINDS OF GIFLEX PIPES
|
GIFLEX "N" : WITHOUT
EXTERNAL BRAID
GIFLEX "N1" : ONE BRAID COATED
GIFLEX "N2" : TWO BRAIDS COATED
|
|
DN
|
Ĝi
|
Bend radius constant flexure
|
Bend radius permanent bending
|
Hose type
Giflex "N"
|
Hose type
Giflex "N1"
|
Hose type
Giflex "N2"
|
| |
mm
|
mm
|
mm
|
De
mm
|
Pn
Kg/cm2
|
De
mm
|
Pn
Kg/cm2
|
De
mm
|
Pn
Kg/cm2
|
|
1/8"
|
6,2
|
55
|
10
|
9,6
|
5
|
10,8
|
125
|
|
|
|
1/4"
|
8,3
|
60
|
15
|
12,3
|
3
|
13,5
|
100
|
|
|
|
3/8"
|
10,2
|
100
|
18
|
15,1
|
2,5
|
17
|
64
|
19
|
105
|
|
1/2"
|
12,2
|
140
|
20
|
17,7
|
1,6
|
19
|
64
|
22,3
|
100
|
|
5/8"
|
16,2
|
190
|
25
|
22,2
|
1,6
|
24
|
64
|
26,7
|
90
|
|
3/4"
|
20,2
|
230
|
30
|
27,1
|
1,6
|
29
|
50
|
31,8
|
75
|
|
1"
|
25,5
|
260
|
40
|
33,2
|
1,6
|
35
|
50
|
39,3
|
60
|
|
1"1/4
|
34,2
|
290
|
50
|
42
|
1,6
|
44
|
40
|
47,7
|
50
|
|
1"1/2
|
40,1
|
320
|
60
|
51,5
|
1,0
|
54
|
25
|
56,3
|
40
|
|
2"
|
50,4
|
360
|
70
|
63
|
1,0
|
66
|
25
|
69,5
|
32
|
|
2"1/2
|
65,4
|
420
|
80
|
80
|
1,0
|
83
|
16
|
90,4
|
25
|
|
3"
|
80,2
|
480
|
100
|
97
|
1,0
|
100
|
16
|
102,5
|
22
|
|
4"
|
100,2
|
580
|
120
|
119
|
1,0
|
122
|
16
|
130,5
|
20
|
|
5"
|
126,2
|
680
|
150
|
146
|
1,0
|
150
|
16
|
157,5
|
18
|
|
6"
|
149,8
|
800
|
200
|
173
|
0,8
|
177
|
12,5
|
183
|
15
|
|
8"
|
200
|
950
|
260
|
227
|
0,8
|
232
|
10
|
|
|
|
10"
|
250
|
1200
|
340
|
281
|
0,6
|
287
|
8
|
|
|
|
12"
|
300
|
1600
|
420
|
334
|
0,5
|
340
|
4
|
|
|
NOTE:
This kind of hose is assure to the carriage of fluids, gas,
with pressure, empty or vibrations in general.
|
|
